The premium ISIS bottom bracket cartridge ensures greater surface area contact, a sturdier connection, and less maintenance than a traditional square joint. This same bottom bracket cartridge is used on high end bicycles. There are many key components responsible for optimum performance of an indoor cycle. The Hutchinson drive belt, ISIS bottom bracket cartridge, pulley size and material, gear ratio and three piece crank have been carefully chosen on the CIC800 and incorporated into the overall design to assure optimal performance and durability. These components, along with an ergonomically correct frame design and full fore/aft/up/down adjustability, combine to make the perfect indoor cycle for your facility.
FEATURES
- Foot Pedals: As with any product, customization is of extreme importance. We addressed this issue with a dual function pedal. On one side is a standard flat surface with a toe cage that appeals to the average exerciser. On the other side is a premium SPD clip that will be utilized by avid cyclists.
- Flywheel: Perimeter weighted, high-inertia 37 lbs. flywheel
- ISIS Spline: The splined receiver for the pedal cranks enhances stability and requires less maintenance than a square receiver.
- Bearings: Needle bearings that encompass the flywheel and pedal/crank joint promote quiet, fluid rotation.
- Paint Durability: Durable Powder-Coat Paint
- Frame Durability: A 126 lb. frame consisting of 2.5mm thick oval tubing and round bars that enhance stability and promote longevity
- Contact Points: The co-molded rotary resistance/brake knob and “L” shaped joint adjustment handles promote comfort
- Efficiency: Rear joint cover offers a convenient, effective calf stretch.
- Stability: Oversized floor casters provide a stable base of support for simulated climbs out of the saddle and heavier riders.
- Comfort: Micro fore/aft adjustments on seat and handlebars
- Clarity: Aluminum seat and handlebar post with stamped height settings for quick reference.
SPECIFICATIONS
- Resistance: Magnetic, Rotary Knob; Micro Adjustments
- Drive Train: Industrial Grade Hutchinson Poly-V Belt and ISIS Oversized Bottom Bracket
- Flywheel: Perimeter Weighted 37lbs Flywheel; High Inertia System
- Seat: Racing Saddle
- Frame: High Strength Steel with Durable Powder Coat Paint
- Handlebar: PVC coated, Multi-Grip Design, Built-In Water Bottle Holder
- Handlebar/Seat Posts: Aluminum with Stamped Numerical Height Indicators
- Adjustments: Up/Down - Reliable Pop-Pin Adjustments; Fore/Aft - Knob Tightening Micro Adjustments.
- User Size Range: Typically 4’11” to 6’5” tall
- Dimensions: 42” X 21” X 41”
- Product Weight: 126 lbs.
- Maximum User Weight: 350 lbs.
- Foot Pedals: Dual Sided with SPD & Toe Cage
COMMERCIAL WARRANTY: (Dues Paying Facility)
- Frame: 10 Years
- Parts: 3 Years
- Labor: 1 Year
- Wear Items (Grips & Toe Cage Straps): 1 Year
COMMERCIAL WARRANTY: (Non-Dues Paying Facility)
- Frame: 15 Years
- Parts: 3 Years
- Labor: 1 Year
- Wear Items (Grips & Toe Cage Straps): 1 Year
