It's your ride so make it the best with the Spinner® NXT, manufactured by Star Trac®. This premium indoor cycling bike combines user-focused features with a high degree of adjustability and comfort. To maintain uncompromising quality ride after ride, the Spinner® NXT features rust-defying two-stage powder coating and rock solid construction for lasting performance as well as an increased five degree handlebar angle for a more comfortable riding position and an improved Q-factor for the most authentic ride.

Features

• Sleek steel frame design with zinc dip coating for superior rust protection.
• Handlebars and seat settings provide vertical and fore/aft user adjustment for optimal bike fit.
• Dual oversized easy access water bottle holders integrated into the handlebars.
• Patent-pending taper fit bottom bracket and pedal system for increased strength and reliability.
• Superior biomechanics with a Q-factor of 158 mm.
• 38 lbs (17.2 kg) perimeter weighted flywheel for a smooth and realistic riding experience.
• Powerful chain drive system delivers an authentic road riding feel.
• Custom dual-sided SPD®-compatible pedals feature a large pedal body while accommodating both SPD® and toe clip.
• Smooth control resistance knob with direct pressure emergency stop.
• Front mounted wheels for easy transport and movement.
• Non-rusting urethane/over-molded leveling feet for easy leveling.
• High impact urethane rear stretch guard and step guards to prevent damage to frame from cleated cycling shoes.
• Accommodates riders 4' 10" (147.3 cm) to 6' 10" (208.3cm) with a maximum recommended weight capacity of 350 lbs (158.8 kg).

Specifications

• Overall Dimensions*: 20in. w × 60in. l × 57in. h (20 × 152.4 × 144.78 cm)
• Overall Weight: 140 lbs (63.5 kg)
• Flywheel Weight: 38 lbs (20 kg)
• Color: Frame: Star Trac Silver, Shroud: Black, Flywheel: Black

The SC1 comes standard with the following premium features:

• Bike Weight: 114 lbs (51.5 kg).
• Bike Dimensions: 20” W x 50.5” L (50.9 cm W x 128.2 cm L).
• Frame Material & Construction: Chrome-moly steel, mandrel-formed steel, TIG weld.
• Frame Finish & Color: Industrial powder coat, Slate Grey.
• Assembly Hardware: Stainless steel.
• Drive System: CarbonGlyde featuring Gates® Carbon Drive™ carbon fiber belt.
• Gear Ratio: 5:1.
• Resistance System: Magnetic Eddy current with micro-adjust resistance dial, emergency push-to-stop.
• Q-Factor: 160 mm.
• Handlebars: Comfort coated aluminum Stages RhythmBar.
• Adjustment System: StagesFit with standard pop-pin height & patented fore-aft adjustment.
• Flywheel: High-inertia, cast iron perimeter weighted.
• Pedals: SPD & toe cage.
• Rider Fit Range: 4’10” (147cm) to 6’10” (208cm).
• Max User Weight: 350 lbs (158 kg).
• Power Measurement: Optional, not included.

Warranties:

• Frame: 10 yrs.
• CarbonGlyde Carbon Fiber Belt: 10 yrs.
• Mechanical System: 3 yrs.
• Labor & Electronics: 1 yr.
• Wear Items: 6 mos.

The Stages SP4 Toe Cages are a premium accessory designed for indoor cycling enthusiasts, developed in collaboration with LOOK Cycle. These toe cages leverage the combined expertise and patents of both Stages and LOOK to deliver a versatile pedal system suitable for a wide range of shoes used in gyms or home training.

Features:

1. Compatibility: The toe cages are designed to be compatible with various shoes and cleats. They support regular athletic shoes with the Platform-Cage, are equipped with a removable athletic shoe platform for LOOK Delta cleats, and feature a new strap retention system for quick and easy adjustments.

2. Tool-Free Platform Removal: The platform is easily removable without the need for tools. A spring-loaded lever facilitates the quick and effortless removal of the platform.

3. Easy Installation: These toe cages can be effortlessly installed on any indoor cycling bike that utilizes a 9/16" - 20 threaded spindle, making them convenient for users looking to enhance their cycling experience.

4. Redesigned Spindle: The SP4 toe cages utilize a specially designed spindle to ensure extended durability, providing users with a reliable and long-lasting accessory.

5. Larger Platform Body and Cage: With a larger platform body and cage, these toe cages can comfortably accommodate larger shoe sizes, offering extra comfort during indoor cycling sessions.

6. Weight: The toe cage set has a weight of 424 grams, ensuring a lightweight yet sturdy addition to your indoor cycling setup. The platform set weighs 450 grams.

7. Warranty Period: Stages offers a one-year warranty for the SP4 Toe Cages, providing users with confidence in the product's quality and performance.

Specifications:

• SKU: 000-6125
• Condition: New

The PRO™ Power offers all the features of the PRO™, plus high-accuracy power measurement with the included SPINPower® Studio Console and SPINPower® Studio Crank. The highly accurate (+/- 1%) power measurement crank connects wirelessly to the console. Bluetooth™ and ANT+ compatibility enables it to connect to popular apps and leaderboard systems.

The PRO™ Power fuses a sleek profile with high-accuracy power measurement along with our tried and true Linear Resistance System™ for authentic cycling training and the feel of real road bikes.

Fit, form and functionality

Riders will love the sleek profile, open-frame design and matte black finish of the PRO™ Power! The PRO™ Power features our proprietary Linear Resistance System™ to deliver on our promise to make bikes that feel right and stay true to our cycling heritage. With maximum adjustability, including fore/aft on the handlebars, riders get a custom fit and a more efficient ride.

High-accuracy power measurement

The PRO™ Power features high-accuracy power measurement with the included SPINPower® Studio Console and SPINPower® Studio Crank. The highly accurate (+/- 1%) power measurement crank connects wirelessly to the console. Bluetooth™ and ANT+ compatibility enables it to connect to popular apps and leaderboard systems. Equipped with a large, ultra-bright color display, the console is easy to use is powered by an integrated generator system that eliminates the need to replace batteries.

Legacy Details

The Fusion Drive® Belt System delivers a smooth, silent, and virtually maintenance-free ride while the 43 lb (19.5 kg) perimeter-weighted flywheel creates an authentic cycling feel for both performance and rhythm-based riding. Combined with a perimeter-weighted flywheel, the powerful and simple resistance system mimics the feel of being on the road and infinitely adjusts to suit the needs of every rider. Our umbrella design concept has been incorporated throughout the entire bike – with virtually no flat surfaces or entry points for sweat!

SKU: 10-027-PLUS-KIT

Specifications:

• Overall Dimensions: 46.0” Long X 20.2” Wide X 48.4” Height (116.9 x 51.4 x 123.0 cm)
• Overall Weight: 130 lbs (59 kg)
• Flywheel Weight: 43 lb (19.5 kg), perimeter-weighted
• Pedal Type: Dual-Sided SPD®-Compatible Pedals
• Color: Midnight Metallic Black
• Weight Limit: 350 lbs (158.8 kg)

Warranty

• Frame: 10 years
• Mechanical Parts: 2 years
• Labor: 1 year
• Wear Items: 90 days
• Console: 1 year

Features:

SPINPower® Studio Crank This highly accurate (+/- 1%) power measurement crank is easy to maintain and wirelessly connected to the bike's computer. It offers Bluetooth and ANT+ compatibility, enabling connection to popular apps and leaderboard systems.

Self-Powered Console The console is equipped with a large, ultra-bright color display and is easy to use. It is Bluetooth™ and ANT+ compatible, and it is powered by an integrated generator system, eliminating the need for battery replacements.

Fusion Drive™ Belt System The Poly-V Belt drivetrain provides a smooth, silent, and virtually maintenance-free ride.

43 lb Perimeter Weighted Flywheel The 43 lb (19.5 kg) perimeter-weighted flywheel creates an authentic cycling feel suitable for both performance and rhythm-based riding.

Frame Design and Geometry The bike features a sweat-resistant, powder-coated steel and open frame design with an umbrella concept, ensuring virtually no flat surfaces or entry points for sweat.

Wedge Design Handlebar and Seat Post An all-new wedge design keeps the handlebar and seatpost secure and solid while remaining easy to adjust.

Micro-Adjustable Resistance Combined with the perimeter-weighted flywheel, the powerful and simple resistance system replicates the feel of being on the road and infinitely adjusts to suit the needs of every rider.

Fore/Aft Handlebar Adjustability Micro-adjustable fore/aft sliders on the handlebar allow for a precise custom fit.

Fully Adjustable Saddle Precision vertical adjustments, paired with micro-adjustable fore/aft sliders on the saddle, allow for an optimal fit and enhanced comfort.

Dual Water Bottle Holder A sturdy, oversized dual water bottle holder on the handlebars allows for easy access to hydration.

Dual-Sided SPD®-Compatible Pedals The dual-sided pedals accommodate both athletic and cycling shoes, offering riders more flexibility and functionality.

Easy Transport Wheels and Stabilizer Feet Front-end wheels enable easy portability, while stabilizer feet eliminate shaking, providing stability during your ride.

SAY HELLO TO SCHWINN® TRIPLE LINK™ SDL PEDALS

Triple Link pedals give users the freedom to choose between strapping in with the use of toe cages or using cycling shoes with the SPD® and Look® Delta or Keo compatible clips. Our pedals use a patent pending threaded-less rod that virtually eliminates the potential for the pedal to break or back out of the crank. With easy installation and worry-free performance, we think it’s the best thing to happen to pedals since the clip.

Click here to download installation manual

Stages takes the guesswork out of training, both on the road and in the studio. Many elite outdoor cycling teams and individuals choose Stages Power because when using the most accurate measure of performance, they can develop and adhere much more precisely to their fitness goals. Now your studio riders can benefit from the same precise data professionals use, and map their fitness strategies to more quickly reach their own goals.

The SC3 comes standard with the following premium features:

• Bike Weight: 96 lbs (43 kg).
• Bike Dimensions: 24.5” W x 43.5” L (62.23cm W x 110.49cm L).
• Frame Material & Construction: 6061T-6 aluminum alloy, advanced hydro & air formed tubing, TIG weld.
• Frame Finish & Color: Industrial powder coat, Steel Blue.
• Assembly Hardware: Stainless steel.
• Drive System: CarbonGlyde featuring Gates® Carbon Drive™ carbon fi ber belt.
• Gear Ratio: 5:1.
• Resistance System: Magnetic Eddy current with SprintShift resistance lever, microadjust resistance dial, & emergency push-to-stop.
• Q-Factor: 158mm.
• Handlebars: Comfort coated aluminum Stages RoadBar.
• Adjustment System: StagesFit with FitLoc height & patented fore-aft adjustment.
• Flywheel: High-inertia, cast iron perimeter weighted.
• Pedals: SPD & toe cage.
• Rider Fit Range: 4’10” (147cm) to 6’10” (208cm).
• Max User Weight: 350 lbs (158 kg).

Click here to Download Product Sheet
Click here to Download Owner's Manual

REAL POWER. REAL RESULTS.

Packed with all of the best-in-class features of Schwinn’s top tier indoor bikes, the new AC Power bikes take your Authentic Cycling riding experience to a whole new level with the amazingly accurate 4iiii® crank arm powermeter, the new Echelon2G console, and a built in generator, preventing the continuous need to replace batteries.

The premium ISIS bottom bracket cartridge ensures greater surface area contact, a sturdier connection, and less maintenance than a traditional square joint. This same bottom bracket cartridge is used on high end bicycles. There are many key components responsible for optimum performance of an indoor cycle. The Hutchinson drive belt, ISIS bottom bracket cartridge, pulley size and material, gear ratio and three piece crank have been carefully chosen on the CIC800 and incorporated into the overall design to assure optimal performance and durability. These components, along with an ergonomically correct frame design and full fore/aft/up/down adjustability, combine to make the perfect indoor cycle for your facility.

FEATURES

• Foot Pedals: As with any product, customization is of extreme importance. We addressed this issue with a dual function pedal. On one side is a standard flat surface with a toe cage that appeals to the average exerciser. On the other side is a premium SPD clip that will be utilized by avid cyclists.
• Flywheel: Perimeter weighted, high-inertia 37 lbs. flywheel
• ISIS Spline: The splined receiver for the pedal cranks enhances stability and requires less maintenance than a square receiver.
• Bearings: Needle bearings that encompass the flywheel and pedal/crank joint promote quiet, fluid rotation.
• Paint Durability: Durable Powder-Coat Paint
• Frame Durability: A 126 lb. frame consisting of 2.5mm thick oval tubing and round bars that enhance stability and promote longevity
• Contact Points: The co-molded rotary resistance/brake knob and “L” shaped joint adjustment handles promote comfort
• Efficiency: Rear joint cover offers a convenient, effective calf stretch.
• Stability: Oversized floor casters provide a stable base of support for simulated climbs out of the saddle and heavier riders.
• Comfort: Micro fore/aft adjustments on seat and handlebars
• Clarity: Aluminum seat and handlebar post with stamped height settings for quick reference.

SPECIFICATIONS

• Resistance: Magnetic, Rotary Knob; Micro Adjustments
• Drive Train: Industrial Grade Hutchinson Poly-V Belt and ISIS Oversized Bottom Bracket
• Flywheel: Perimeter Weighted 37lbs Flywheel; High Inertia System
• Seat: Racing Saddle
• Frame: High Strength Steel with Durable Powder Coat Paint
• Handlebar: PVC coated, Multi-Grip Design, Built-In Water Bottle Holder
• Handlebar/Seat Posts: Aluminum with Stamped Numerical Height Indicators
• Adjustments: Up/Down - Reliable Pop-Pin Adjustments; Fore/Aft - Knob Tightening Micro Adjustments.
• User Size Range: Typically 4’11” to 6’5” tall
• Dimensions: 42” X 21” X 41”
• Product Weight: 126 lbs.
• Maximum User Weight: 350 lbs.
• Foot Pedals: Dual Sided with SPD & Toe Cage

COMMERCIAL WARRANTY: (Dues Paying Facility)

• Frame: 10 Years
• Parts: 3 Years
• Labor: 1 Year
• Wear Items (Grips & Toe Cage Straps): 1 Year

COMMERCIAL WARRANTY: (Non-Dues Paying Facility)

• Frame: 15 Years
• Parts: 3 Years
• Labor: 1 Year
• Wear Items (Grips & Toe Cage Straps): 1 Year

It's your ride so make it the best with the Spinner® NXT, manufactured by Star Trac®. This premium indoor cycling bike combines user-focused features with a high degree of adjustability and comfort. To maintain uncompromising quality ride after ride, the Spinner® NXT features rust-defying two-stage powder coating and rock solid construction for lasting performance as well as an increased five degree handlebar angle for a more comfortable riding position and an improved Q-factor for the most authentic ride.

Why the Spinner® NXT is right for you: You want the indoor cycling bike that is featured in more clubs than any other indoor cycling bike in the world.

TECHNICAL SPECS

• Length: 44.5″ (113 cm)
• Width: 21″ (53 cm)
• Height: 46″ (117 cm)
• User Weight Capacity: 350 lbs (159 kg)
• Product Weight: 120 lbs (54 kg)

FEATURES

• Customizable options available with frame paint, personally branded decals, and accessories
• Heavy Perimeter-Weighted Flywheel and quiet Poly-V belt Drive Train provide an Smooth Cycling experience
• Direct Pressure Brake Resistance
• 4iiii® crank arm powermeter delivers accurate strain gauge power feedback to help riders train harder and smarter
• On-board generator powers Echelon2G Console without batteries
• Morse Taper pedals and bottom bracket for increased durability and reliability
• Multi-position handlebars accommodate a wide range of choreography
• Find your perfect riding position with easy micro seat and handlebar adjustments
• Frame Finish – Powder Coated Aluminum
• Seat slider and handlebar materials – Aluminum
• Max User Weight 350 lb (159 kg)
• User Height Range 4’11” to 6’8” (150 cm to 203 cm)

All Schwinn A.C.™ indoor bikes come standard with Double Link pedals with SPD and toe-clip combinations to accommodate both cycling cleats and regular athletic shoes. The bikes are also compatible with the Schwinn Triple Link™ pedal upgrade. Triple Link Pedals accommodate Look Delta and SPD style cleats to simulate an outdoor riding experience. They also easily convert to accept traditional athletic shoes with the snap-in locking toe clips. Belt drive using Carbon Blue™ technology Recommended User Height: 4’11” to 6’8″.

The AC Performance bike is Schwinn Triple Link™ pedal compatible. Triple Link Pedals accommodate Look, Delta and SPD style cleats to simulate an outdoor riding experience. They easily convert to accept traditional athletic shoes with the snap-in locking toe clips.

INNOVATION, UNCHAINED.

Introducing Carbon Blue™ technology – a belt drive system combining unmatched durability with the authentic outdoor biking feel you expect from Schwinn. For nearly 20 years, Schwinn carbon blue belt drive bikes have led the indoor cycling industry. Even as other companies began to use belt drives, we stayed true to our technology for one simple reason: belt drives felt nothing like riding an outdoor bike. Today, all of that is changing. There is a revolutionary new belt drive taking the outdoor bike community by storm, and we’ve adapted it and brought it indoors on the A.C. Performance. This next generation system delivers guaranteed durability and virtually zero maintenance, without sacrificing the Schwinn authentic cycling feel that riders know and love.

CARBON BLUE™

Several years ago, a company named Gates introduced a concept never before seen on outdoor bikes – a belt drive that performed like a chain. Their innovative system – called Carbon Drive™– features a carbon fiber reinforced belt with teeth for maximum durability and true bike performance. Over time, this has transitioned from a novelty system to a mainstream solution used on hundreds of outdoor bike models today. Over the past year, we have worked with Gates to adapt this revolutionary technology to our A.C. Performance bike. The result is a new belt-based drive system that combines the maintenance-free durability and performance of a belt with the authentic-ride feel of a chain. We call it Carbon Blue ™ – those who ride it call it “incredible.”

BENEFITS OF CARBON BLUE™

LOW MAINTENANCE

• Belt never requires lubrication
• Tension never needs to be adjusted

REAL BIKE FEEL

• High-inertia drive train provides momentum and feel of chain drive
• Toothed belt provides rider feedback and road feel

FEATURES

• High Performance handlebars support all rider needs, from comfort to high-performance
• Virtual Contact™ Magnetic resistance brake allows for smooth, consistent control
• Schwinn Fit system enables a wide range of seat and handlebar adjustments to provide a safe and comfortable setup for a wide range of riders

5-YEAR WARRANTY

• Carbon fiber reinforcement makes this belt incredibly durable
• The longest warranty of any belt or chain on the market

TECHNICAL SPECS

• Product Dimensions: 54" L x 21" W x 51" H (137cm x 53cm x 130cm)
• Product Weight: 102 lbs (46 kg)
• Max User Weight: 350 lbs (159 kg)
• Frame Finish: Aluminum
• Frame Color: Pearl White
• Seat Slider, Handlebars and Hardware Materials: Aluminum
• Drive System: Belt drive using Carbon Blue™ technology
• User Compatible Size Range: Typically 4'11" to 6'8" (150 to 203 cm) tall
• MPower™ Echelon Console Compatible: Yes
• Q Factor: 170mm
• This unit requires Morse Taper Pedals, please call for details

Commercial Warranty

Frame: 10 years Mechanical: 2 years Wear items: 6 months Labor: 1 year

Click here to Download Product Sheet
Click here to Download Owner's Manual

Engineered with innovative features like an oversized, heavy-duty steel frame, our Spinner® NXT™ is built to be a performance workhorse for your facility. With integral contoured sweat guards that protect against moisture and rust, the NXT™ stands up to rigorous usage with low overall maintenance. Maximum adjustability on the seat and handlebars ensures an optimal fit for riders of most sizes. Enhance the indoor cycling experience by adding power-meter technology with a SPINPower® Studio Crank.

Spinning® is the original, authentic indoor cycling experience and we’ve been designing bikes for fitness facilities and studios around the world for nearly 30 years! Our bikes are made to fit riders of all shapes, sizes and abilities and replicate the feel and geometry of real road bikes with elegant and durable designs.

We continue to pour that same authenticity and expertise into every single bike that we design. Built specifically for the studio or fitness facility environment, the Spinner® NXT™ is designed to withstand the rigors of thousands of classes over many years!

Engineered for high-performance, The Spinner® NXT™ uses oversized, heavy-duty commercial grade crank arms – the strongest and most durable on the market, designed for low maintenance and longevity. Can be upgraded by adding power-meter technology with a SPINPower® Studio Crank, allowing your riders to measure true output and effort. The SPINPower® Studio Crank provides an accurate (+/- 1%) power measurement, making it one of the most accurate power solutions for indoor bikes.

The NXT™ features a 350 lb weight limit and dual-sided SPD®-compatible pedals so you can ride with either sneakers or cycling shoes. The 43-lb (19.5 kg) flywheel and drivetrain give you the authentic road bike feel that Spinning® pioneered.

Oversized Steel Frame

Spinner® NXT™ boasts a larger, heavy duty design providing durability and optimal stability.

Maximum Adjustability for an Efficient Ride

The right fit means more comfort and better efficiency every time for every rider. The Spinner® NXT™ features maximum adjustability on the seat and handlebars: handlebar height and fore/aft (forward and backward) plus seat height and fore/aft. The handlebar and seat fore/aft allow for micro adjustment, meaning riders can customize the fit at a very specific level.

Rider Height and Weight

Designed for a wide range of riders, the NXT™ supports riders up to 350 lbs and heights between 4’11 and 6’4. Keep in mind that 4’11 is not an exact minimum height because leg and torso length are the determining factors.

With its maximum adjustability, the NXT™ is one of the few indoor bikes on the market that allows for handlebars to adjust fore and aft, which helps you customize your reach so you can ride with increased comfort.

A Smooth, Quiet Ride

The Fusion Drive® Belt system, with an ultra-durable Poly-V Isoprene belt, delivers a smooth, silent and virtually maintenance-free ride. An oversized one-bolt panel allows you improved access to the drivetrain for easy maintenance.

Endurance is part of our Design DNA

Built for the facility and studio environment, the commercial line of Spinner® bikes is designed to withstand the rigors of thousands of classes over several years. All frame materials are powder-coated for superior corrosion resistance and lasting protection from sweat and moisture to deliver exceptional durability. The “Umbrella Style” resistance knob protects the internal mechanical components from sweat and in fact, we’ve incorporated this umbrella design concept into the entire bike! Every component is designed to shed sweat and increase the durability and longevity of the bike. There are virtually no flat surfaces and components fit perfectly together so that there are little to no entry points for sweat.

Precision Resistance without Limits

The high quality leather brake pad on the Spinner® NXT™ provides for a smooth ride, infinite resistance and minimal maintenance. It allows the rider precise control to dial into the desired resistance and hold that resistance - whether pedaling fast or slow.

Hydration within Reach

We’ve added a sturdy, oversized dual water bottle holder to the handlebars so that hydration is within reach anytime during the ride.

Performance Saddle

The saddle of the NXT™ features racing-style road bike geometry with a sleek silhouette that promotes freedom of movement and comfort. The adjustment knob has an anatomical grip design that allows for ease of tightening. The saddle’s low profile and performance cushioning is perfect if you are a frequent rider because it allows for full movement and helps prevent chafing.

Dual-Sided SPD®-Compatible Pedals

All of our Spinner® bikes, including the Spinner® NXT™, feature dual-sided pedals that accomodate shoes with SPD® cleats or athletic shoes. Our commercial bikes feature Morse Taper pedals for increased durability.

Genuine Road Bike Ride Geometry

The measured space between the pedals, the Q factor, is an important element for comfort and performance. Spinner® bikes feature a precise Q factor that is modeled after road bikes to deliver better comfort and biomechanics through the hips, knees and ankles.

Transportability

Front-end wheels make it easy to roll your bikes for quick and easy cleaning and/or to move them out of the way after the class. Wherever you place it, the adjustable leveler feet will ensure stability! Injection molded stretch guards on rear stabilizer feet allow students to easily stretch out their calves, while eliminating the wear and tear on the paint - keeping your Spinner® NXT™ in tip-top shape for years to come.

SKU: 10-028

Specifications:

• Overall Dimensions (MAX): (L x W x H) 48” L x 20” W x 50” H (122 x 52 x 127 cm)
• Overall Weight: 140 lbs (63.5 kg)
• Shipping Dimensions: 47” x 39” x 11” (119 x 99 x 28 cm)
• Shipping Weight: 151 lbs (68.5 kg)
• Flywheel Weight: Heavier 43 lb (19.5 kg), perimeter-weighted
• Pedal Type: Dual-Sided SPD®-Compatible Pedals
• Color: Satin Metallic Silver
• Weight Limit: 350 lbs (158.8 kg)

Warranty

• Frame: 10 years
• Mechanical Parts: 2 years
• Labor: 1 year
• Wear Items: 90 days

Features:

Fusion Drive™ Belt System The Poly-V Belt drivetrain delivers a smooth, silent, and virtually maintenance-free ride thanks to aramid fibers that provide strength and flexibility.

43lb Perimeter Weighted Flywheel The 43 lb / 19.5 kg flywheel and drivechain provide the smooth and authentic road bike feel that Spinning® is known for.

Sweat-Resistant, Powder-Coated Steel and Open Frame Design The umbrella design has been incorporated throughout the entire bike, with virtually no flat surfaces or entry points for sweat to pool. All components fit perfectly together, preventing sweat from getting into seams and causing corrosion.

Wedge Design Handlebar Post The all-new wedge design keeps the handlebars secure and solid while remaining easy to adjust. The added fore/aft adjustment feature on the handlebars of the NXT™ offers more comfort and proper upper body extension, reducing unnecessary strain on the neck and back.

Fore/Aft Handlebar Adjustability Fore/aft (forwards and backwards) handlebar adjustability for a custom fit to maximize performance.

Dual Water Bottle Holder A sturdy, oversized dual water bottle holder on the handlebars allows easy access, ensuring hydration is within reach throughout the ride.

Adjustable Resistance and Quick Stop The "umbrella" style resistance knob protects the internal mechanical components from sweat and allows for precise adjustments and quick stops.

Fully Adjustable Seat Fore/aft (forwards and backwards) micro adjustment allows for superior performance, maximum comfort, and an optimal fit for riders of most sizes. The adjustment knob features an anatomical grip design for ease of tightening.

Dual-Sided SPD®-Compatible Pedals Pedals accommodate both athletic shoes and cycling shoes for increased pedaling efficiency, ideal for cross-training or riders who choose to wear athletic shoes. Commercial Spinner® bikes feature Morse Taper pedals for increased durability.

Leather Brake Pad This high-quality leather brake pad provides a smooth ride, infinite resistance, and minimal maintenance, allowing precise control over the resistance whether pedaling fast or slow.

Easy Transport Wheels and Stabilizer Feet Front-end wheels allow for easy portability while stabilizer feet eliminate shaking. Injection-molded stretch guards on rear stabilizer feet eliminate wear and tear on the paint.

Heavy-duty Commercial Crank Features a commercial-grade crank designed for low maintenance and longevity. Upgrade by adding power-meter technology with the SPINPower® Studio Crank for accurate power measurement.

The NEW Blade ION Connected Spinner® Bike revolutionizes your home workouts with its integrated power capabilities, offering precise power measurement. Experience accurate power output measurement with an impressive +/-1% error margin, setting a new standard in power measurement for home fitness equipment. The Blade ION features a 40-lb perimeter-weighted flywheel and drivetrain, providing the genuine road bike feel pioneered by Spinning®. With the Fusion Drive® Belt System, it ensures a smooth and quiet ride. Boasting maximum seat and handlebar adjustability, a 350 lb weight limit, and dual-sided SPD® compatible pedals, the Blade ION takes your home workouts to the next level.

Spinning® is the original, authentic indoor cycling experience, and we've been designing bikes for your favorite studios for nearly 30 years. Our bikes are crafted to accommodate riders of all shapes, sizes, and abilities while replicating the feel and geometry of real road bikes with elegant and durable designs.

We continue to infuse the same authenticity and expertise into every bike we design.

The Blade ION Connected Spinner® Bike is engineered for high performance and is the ideal choice for home athletes or anyone looking to elevate their indoor cycling game. It includes a SPINPower® Performance Crank, allowing you to measure your true output and effort accurately. The included crank provides a precise power measurement with an error margin of just +/- 1%, making it one of the most accurate power solutions for indoor bikes. The Blade ION supports riders up to 350 lbs and offers dual-sided SPD®-compatible pedals, allowing you to ride with either sneakers or cycling shoes. With a 40-lb flywheel and drivetrain, you'll enjoy the authentic road bike feel pioneered by Spinning®. Plus, the integrated tablet mount and dual water bottle holder add convenience to your ride.

Maximum Adjustability:

The Blade ION prioritizes the right fit for maximum comfort and improved efficiency every time you ride. It offers extensive adjustability for the seat and handlebars, including handlebar height and fore/aft, as well as seat height and fore/aft. The microadjustment feature for both handlebars and seat allows for a highly customized fit.

Rider Height and Weight:

Designed to accommodate a broad range of riders, the Blade ION supports individuals weighing up to 350 lbs and with heights between 4'11" and 6'5". Please note that the minimum height is not a strict 4'11" as leg and torso length play crucial roles.

A Smooth, Quiet Ride:

The Fusion Drive® Belt System provides a smooth, silent, and virtually maintenance-free riding experience.

Endurance as a Design Principle:

Endurance isn't just a category; it's ingrained in our design philosophy. The "Umbrella Style" resistance knob safeguards internal mechanical components from sweat. In fact, this umbrella design concept is integrated throughout the entire bike. Every component is meticulously designed to repel sweat, enhancing the bike's durability and longevity. With virtually no flat surfaces and perfectly fitting components, there are minimal entry points for sweat. This design ensures you can enjoy the physical and emotional benefits of Spinning® for years to come.

Precision Resistance without Limits:

The Blade Ion features a leather brake pad that allows precise control over your resistance. You can dial in the exact resistance you desire and maintain it even when you pedal faster or slower. This feature provides precise control for tackling steep hills or powering through sprints.

Hydration within Reach:

We've added a sturdy, oversized dual water bottle holder to the handlebars, ensuring that you can hydrate without having to bend uncomfortably during intense intervals.

Performance Saddle:

The Blade ION's commercial-grade saddle is designed with racing-style road bike geometry, featuring a sleek silhouette that promotes freedom of movement. Its low profile and performance cushioning are ideal for frequent riders, allowing full movement and helping to prevent chafing.

Dual-Sided SPD®-Compatible Pedals:

All our home Spinner® bikes, including the Blade ION, come equipped with dual-sided SPD®-compatible pedals. You can ride with athletic shoes or sneakers using the adjustable toe cages and straps or clip in with your SPD® cleats. We recommend starting with SPD® cleats for an efficient, powerful, and safe ride by optimizing your pedal stroke, reducing foot fatigue, and enhancing safety and support.

Genuine Road Bike Ride Geometry:

The Blade ION's Q Factor closely mimics that of a road bike. This ensures increased efficiency and reduces the risk of injury. Consistent with the Q Factor of an outdoor road bike, the Blade Ion enhances biomechanics and alignment through the hips, knees, and ankles.

Transportability:

Front-end wheels make it easy to roll your bike to your preferred workout spot and move it out of the way after your ride. Adjustable leveler feet ensure stability on uneven floors.

Powered by You:

Our content is delivered through your mobile device and connects to your sensors, such as a heart rate monitor, cadence sensor, and/or power crank. This eliminates the need for the bike to be near a power source or plugged in.

Customize Your Ride:

The Blade ION offers one of the most flexible indoor cycling experiences on the market. The Integrated Tablet Mount accommodates tablets with up to a 9" span (up to a 12.9" tablet). The sturdy design ensures your screen stays secure and steady, even during intense rides. If you're using your phone for content, metrics, or staying in touch during your ride, the flat center section provides a secure spot for your phone, keeping it out of the "sweat zone."

You have the freedom to choose your content, sensors, and device, whether it's a tablet, phone, or TV. The Blade ION can be used without relying on power or software, giving you the flexibility to ride with your preferred content or media. While we offer a complimentary subscription with your home bike purchase, you don't need a subscription or membership to use the bike. It's your ride, your way.

SKU: 10-035-TM

Specifications:

• Overall Dimensions: 1145mm Long x 502mm Wide x 1425mm Tall (average, without tablet installed)
• Overall Weight: 123.5 lbs (56 kg)
• Flywheel Weight: 40 lbs, perimeter-weighted
• Color: Black
• Weight Limit: 350 lbs
• Drivetrain: Fusion Drive® Belt System
• Pedal Type: Dual-sided SPD® compatible pedals

Features:

• Fusion Drive® Belt System

  • The belt drivetrain delivers a smooth, silent, and virtually maintenance-free ride, thanks to aramid fibers that provide strength and flexibility.

• 40-lb Perimeter-Weighted Flywheel

  • The 40 lb / 18.1 kg flywheel and drivechain provide the smooth and authentic road bike feel that Spinning® is known for.

• Sweat-Resistant, Powder-Coated Steel, and Open Frame Design

  • Integral contoured sweat guards protect against moisture and rust, helping your bike last longer. Our umbrella design concept has been incorporated throughout the entire bike - with virtually no flat surfaces or entry points for sweat! Open step-through frame allows for easy on and off.

• Integrated Tablet Mount

  • The sturdy design keeps your screen secure and steady as you increase the movement and intensity throughout the ride. Accommodates tablets with up to a 9” span (up to a 12.9” tablet). Tablet not included.

• Wedge Design Handlebar Post

  • The added fore/aft adjustment feature on handlebars of the Blade ION offers more comfort and proper upper body extension. Limits unnecessary strain on the neck and back. All-new wedge design keeps the bars secure and solid while remaining easy to adjust.

• Dual Water Bottle Holder

  • A sturdy, oversized dual water bottle holder on the handlebars allows easy access, making hydration within reach throughout the ride.

• Adjustable Resistance and Quick Stop

  • The "umbrella" style resistance knob protects the internal mechanical components from sweat and allows for precise adjustments and quick stops.

• Fully Adjustable Seat

  • Fore/aft micro-adjustment makes for superior performance, maximum comfort, and a personalized fit for riders of most sizes.

• Dual-Sided SPD®-Compatible Pedals

  • Pedals accommodate both athletic shoes and cycling shoes for increased pedaling efficiency.

• Leather Brake Pad

  • This high-quality leather brake pad allows you precise control over your resistance - whether you pedal faster or slower.

• Easy Transport Wheels and Stabilizer Feet

  • Front-end wheels allow for easy portability while stabilizer feet eliminate shaking.

• SPINPower® Performance Crank

  • The Performance Crank allows for accurate measurement of your power output and effort.

REAL POWER. REAL RESULTS.

Packed with all of the best-in-class features of Schwinn’s top tier indoor bikes, the new AC Power bikes take your Authentic Cycling riding experience to a whole new level with the amazingly accurate 4iiii® crank arm powermeter, the new Echelon2G console, and a built in generator, preventing the continuous need to replace batteries.

SUPERIOR DRIVETRAIN

We’ve selected components that are low maintenance and offer uncompromising quality ride after ride. Our patent pending, durable and threadless Morse Taper design keeps the pedals fastened tightly to the bike and prevents breakage. With a best in class bottom bracket Q factor and smooth belt drive, our drivetrain provides a comfortable ride that users will love.

FEATURE-RICH CONSOLE OPTION

Complete the package by incorporating the most popular tools for rider feedback -- time, distance, calories and RPM -- into your ride. Our console brings motivation and measurement to the group cycling studio and is compatible with all Studio bikes. A compact display that is easy to use and easy to read, makes a great bike even better..

TECHNICAL SPECS

• Overall Weight: 120 lbs (55 kg)
• Flywheel Weight: 41 lbs (18.6 kg)
• Width: 21˝ (53 cm)
• Length: 57˝ (144 cm)
• Height: 40˝ (102 cm)
• COLORS: Frame: Metallic Charcoal or Candy Apple Red, Shroud: Black, Flywheel: Black / Red / Silver

The Star Trac Studio 3 brings the traditional indoor cycling bike into the new age with modern style and updated features. The sturdy steel frame, heavy perimeter weighted flywheel, and traditional chain drive give this bike a rock solid build that will keep it moving ride after ride. The Studio 3 is compatible with our feature-rich cycling console that provides motivating user feedback and metrics.

FEATURES

• OPEN STYLED MULTI POSITION HANDLEBARS
• STURDY AND DURABLE FORGED STEEL FRAME WITH RUST RESISTANT POWDER COATING
• HEAVY PERIMETER WEIGHTED FLYWHEEL POWERED BY A TRADITIONAL CHAIN DRIVE
• AVAILABLE CONSOLE TRACKS TIME, DISTANCE, CALORIES AND RPM
• FRAME: Durable Forged Steel with anti-rust coating
• DRIVE TRAIN: Chain Drive with forged steel crank and oversize bottom bracket
• PEDALS: Standard flat pedal; triple link compatible
• ADJUSTMENT: Socketed Seat Adjustment
• COLORS: Frame: Satin Black, Shroud: Black, Flywheel: Black / Red / Silver
• Weight 130 lbs (41 kg)
• Flywheel Weight 41 lbs (18.6 kg)
• Width 22.5” (57 cm)
• Length 50” (127 cm)
• Height 44” (112 cm)

Features

• Sleek steel frame design with zinc dip coating for superior rust protection.
• Handlebars and seat settings provide vertical and fore/aft user adjustment for optimal bike fit.
• Dual oversized easy access water bottle holders integrated into the handlebars.
• Patent-pending taper fit bottom bracket and pedal system for increased strength and reliability.
• Superior biomechanics with a Q-factor of 158 mm.
• 38 lbs (17.2 kg) perimeter weighted flywheel for a smooth and realistic riding experience.
• Powerful chain drive system delivers an authentic road riding feel.
• Custom dual-sided SPD®-compatible pedals feature a large pedal body while accommodating both SPD® and toe clip.
• Smooth control resistance knob with direct pressure emergency stop.
• Front mounted wheels for easy transport and movement.
• Non-rusting urethane/over-molded leveling feet for easy leveling.
• High impact urethane rear stretch guard and step guards to prevent damage to frame from cleated cycling shoes.
• Accommodates riders 4' 10" (147.3 cm) to 6' 10" (208.3cm) with a maximum recommended weight capacity of 350 lbs (158.8 kg).

Specifications

• Overall Dimensions*: 20in. w × 60in. l × 57in. h (20 × 152.4 × 144.78 cm)
• Overall Weight: 140 lbs (63.5 kg)
• Flywheel Weight: 38 lbs (20 kg)
• Color: Frame: Star Trac Silver, Shroud: Black, Flywheel: Black

Stages Coach

The Stages Coach plans are all about the intensity profile and measurable progress. These plans are crafted with progress and performance in mind. Expect repeated blocks of intensities that are sure to 'raise the roof' of your cardiovascular fitness. All Stages Approved Coach Plans carefully consider work to recovery ratios and getting maximal improvement for your time.

Stages MIX

Stages Mix plans are built around visual and audio artistry that will truly allow you to get fully immersed in the ride experience. The class experience is designed to attack targeted power zones like never before with the added motivation of a full tilt experience. The Experience is the main driver to immerse the rider but to still deliver real results.

Specifications:

• Accessories: Optional accessories include Aerobar, Dumbbell Holder, Media Shelf.
• Adjustable: FitLoc provides easy adjustments to seat and handlebar height and fore & aft positions
• Display: Fully immersive screen
• Feedback: Time, Cadence, Watts, Average Watts, Speed and more in the immersive display
• Pedals: SPD & Toe Cage
• Frame: Aluminium
• Finish: Powder Coated
• Resistance System: Unique SprintShift magnetic resistance system allows users to quickly jump resistance levels and use the traditional resistance knob for micro adjustments
• Drive System: CarbonGlyde belt drive system
• Gear Ratio: 5:1
• Q-Factor: 158mm
• Handlebars: Comfort coated aluminium Stages RoadBar
• Cooling Fan: No
• Heart Rate Monitor: Yes
• Connectivity: Ant+ and Bluetooth
• Has wheels: Yes
• Belt Type: CarbonGlyde featuring Gates Carbon Drive carbon fiber belt
• Dimensions: 622 x 1104mm (W x L)
• Weight: 94.7lbs
• Maximum User Weight: 348lbs

Warranty (Commercial):

• Frame: 15 years
• CarbonGlyde Carbon Fibre Belt: 10 years
• Mechanical System: 3 Years
• Electronics: 1 Year
• Wear Items: 6 Months
• Tablet: 1 yr standard.

Click here to download Sell Sheet
Click here to download Spec Sheet

Work harder and train smarter with this revolutionary 4-in-1 compact gym: The Travel Trainr. This versatile workout tool is compact and lightweight, designed to fit in your bag or carry-on, so you can work out anytime, anywhere, no excuses.

The pieces effortlessly collapse and expand to form a Resistance Tube, Push Up Platforms, Ab Wheel, and Jump Rope to offer you a total body workout from strength training to cardio. Wherever life takes you, the Travel Trainer travels with you, so you never miss a chance to reach your goals.

• 4 workout tools in 1: Resistance Tube, Push Up Platforms, Ab Wheel and Speed Jump Rope
• Lightweight yet durable and sturdy construction
• Ideal for travel and fitness on-the-go
• Compact and stores in a travel bag
• Includes a digital exercise guide

Push Up Platforms

You can easily convert the Travel Trainr into push up platforms by snapping in the foam handles on to the top of each side, then start your arm & core workout.

Jump Rope

Get your cardio on by connecting the handles to the lightweight yet durable jump rope cord that is built for speed.

Ab Wheel

Snap in the ergonomic foam grip handles and roll it out with this dual wheel ab roller that will work nearly 20 different muscle groups to build strength and burn fat.

Resistance Cord

Add resistance training to your workout by quickly attaching the cord to each side of the ergonomic handles for a heavy resistance tube ready to work.

Storage

The Travel Trainr is designed to be taken with you anywhere, easily storing all four tools into one bag. The red ergonomic handles snap to the outside of each platform, while the jump rope and resistance tube coil inside, secured by a third rod that is used for the ab wheel. Each platform then clicks together and everything can be slipped into a drawstring storage bag for easy portability.

PRODUCT SPECS

Measurements:

• Ab Wheel: 6.9"L x 6.9"W x 6.5"H
• Push Up Platforms: 6.9"L x 6.9"W x 3.8"H
• Jump Rope: 9.5"L
• Resistance Tube: 50"L; Medium Resistance level up to 30 lbs.
• Weight Capacity: 300 lbs.
• Shipping Weight: 6 lbs.
• Origin: China.
